THE LABELS THAT FIT INSIDE THE FUSEBOX COVERS ON THE EARLY (BIG DASHBOARD) KÜBELWAGEN Typ 82
The labels, scanned from originals I borrowed from Alain COURTONNE, are
printed on white card. I dont know yet the exact dimensions (hint ?),
they let you know where are the fuses for the different circuits. Click
on the image to get the high-definition version, to be printed at 1200
dots per inch.
First click on the picture to get the high resolution scan, then Copy (Right Click, Save As, etc) and print, cut and stick, and make them all jealous at the next VW meet.R.Olgiati 02/02/2007
